  • Model: PCX 13/40E+
  • Weight: 89.00kg
  • Dimensions: 1,107.00mm x 400.00mm x 960.00mm
  • SKU: 123456789
£0.00
Ex Tax: £0.00

Description

Heavyweight Battery Powered Plate Compactor

Heavyweight, professional combination compaction plate designed with an emission free, Li-ion battery powered motor for all your compaction requirements, indoor usage and poorly ventilated areas. Produces low HAV values and matches the high-performance compaction of its petrol powered equivalent, but without the environmental impact... ...Building a Sustainable Future!

  • Fitted with a robust, highly efficient brushless Honda eGX motor
  • Lithium Ion battery, interchangeable with other Honda eGX powered Altrad Belle products.
  • Environmentally friendly, emission free for use indoors & in poorly ventilated areas such as basements and tunnels.
  • Low noise offers increased working hours and usage in noise restricted areas.
  • High performance 13kN vibration unit gives excellent travel speed and compaction force, reducing operating times.
  • Low operating HAV levels, gives more than 8hrs operator trigger time.
  • Foldable mounted guide handle offers superior manoeuvrability and can be lowered to operate under obstacles and close to form work.
  • Reinforced centrifugal clutch ensures longer belt life, and simplified belt adjustment.
  • Single switch operation makes starting the power unit easy. No choke or recoil start.
  • 3-speed selector, allowing slower speeds when working around obstacles.
  • No routine power unit maintenance eliminates servicing or costly downtime due to repairs. no blocked carburettors
  • Robust protective battery cover & steel sub frame. With integrated battery power level viewing window.
  • Lifting points and front lift cage offer easier loading and unloading for operator convenience.
  • Optional, large 9.5 litre water tank is built into the main frame for added protection.
  • The spray bar is fully protected from damage, easily positioned, with integral paving pad clamp points.
  • Angled holes on spray bar allow complete water coverage over the full width preventing any asphalt pick-up on plate bottom.
  • Life lubricated vibration bearings.
  • Block Paving Pad and Wheel Kit options also available.
  • Customer colour options available.
RefModelMotor
Power
(Hp/kW)
Plate Size
W x L
(mm)
Static
Pressure
(kg/m2)

Frequency
(Hz)

Centrifugal
Force
(kN)
Max
Gradient
(°)
Travel
Speed
(m/min)
Vibration
(m/sec2)
Motor
RPM
80% Battery
Charge
Time (mins)
100% Battery
Charge
Time (mins)
Weight
(kg)
FC4050EPCX 13/40E+2.2 / 1.6400 x 606560101132020<2.53600 / 3000 / 2800507589
OPP/108/DIOeGX Battery
OPP/109/DIOeGX Battery Box
OPP/109/DIO
eGX Battery Charger
OPP/111/DIOCharger Storage Box
